Thermal conductivity measurement webinar: from TIMs to diamond

September 29, 2026 Jeff Braun
Register now

From soft TIMs to CVD diamond: join our Thermal Live Fall 2026 session on thermal conductivity measurement

Jeff Braun shows how one non-contact platform now measures materials from gels and pastes to diamond wafers, and how to pick the right method for yours.

Most thermal conductivity measurements were designed for ideal samples: solid, uniform, machined to a set shape, and inside one narrow conductivity range. Real materials rarely cooperate. Thermal interface materials are pastes squeezed between a die and a heat sink. Heat spreaders and wafers move heat sideways, not straight through. And a single product can include materials that span five orders of magnitude in conductivity.

When the method’s assumptions don’t match the material, the data stops being reliable.

On Wednesday October 14 at 12.45PM (EST), Laser Thermal’s Jeff Braun, Vice President of Programs and Strategy, will present Overcoming Challenges in Thermal Conductivity Measurement, from Soft TIMs to CVD Diamond at Thermal Live Fall 2026. The session covers how TOPS measures thermal conductivity from 0.01 to 3,000+ W/m·K on one instrument, using two complementary methods.

What’s new since our spring session

If you joined us in May, this session goes further. TOPS now includes lock-in infrared thermography (LIT), a phase-based method with strong sensitivity to in-plane thermal conductivity. Jeff will share validation data from fused silica to a CVD diamond wafer measured at 2,490 W/m·K, plus results showing that unpolished wafer backsides and rough surfaces don’t change the answer.

What you’ll learn

  • How steady-state and lock-in thermography methods work, and when to use each
  • How TIMs, gels, pastes, and liquid metals are measured directly, without compression or solidification
  • How thermal mapping (up to 150 × 150 mm) reveals uneven TIM application and hidden subsurface damage in PCBs and coatings
  • What sample geometry, heat capacity, and film thickness mean for your measurement, and when a thin-film tool such as FASTR is the better fit

Who should attend

Thermal engineers, packaging and materials scientists, and R&D and quality teams working with TIMs, heat spreaders, substrates, wafers, or coatings. It’s especially relevant if you’re qualifying new materials or checking supplier datasheets.

Jeff will take audience questions live after the presentation.

Register now

Have a sample that’s hard to measure?
Send us the material, the geometry, and the question you need answered. We’ll tell you what’s possible.

Contact us
Jeff Braun

Jeff Braun

Jeff Braun drives the research and development of next-generation thermal metrology platforms at Laser Thermal, alongside the programs that bring them from concept to deployment.
He earned his Ph.D. in Mechanical and Aerospace Engineering from the University of Virginia, where he invented and patented Steady-State Thermoreflectance, the measurement method at the core of one of Laser Thermal’s primary instrument platforms. Before joining Laser Thermal, he served as a program manager at Northrop Grumman, working in superconducting and quantum computing as well as digital transformation. Earlier in his career, he held roles in systems engineering and intelligence analysis at the Office of Naval Intelligence.
At Laser Thermal, Jeff leads government and commercial programs, including serving as principal investigator for R&D contracts. Additionally, Jeff has invented the thermo-optical plane source (TOPS) technique and led the product development to transition it into our commercial product. His combination of deep metrology expertise and program management experience allows him to bridge the gap between scientific innovation and the operational and contractual demands of bringing advanced instrumentation to market.
Outside of work, Jeff loves being a dad and his hobbies include skiing, kayaking, and cooking.
